Chipanalog CA-IF1022DF-Q1 Interface IC
Share
pThe CA-IF1022 is a Local Interconnect Network (LIN) dual channel transceiver, which is a low speed Universal Asynchronous Transceiver (UART) communication protocol that supports automotive in vehicle networks./p
- Product Details
- Download
Chipanalog CA-IF1022DF-Q1
The CA-IF1022 is a Local Interconnect Network (LIN) dual channel transceiver, which is a low speed Universal Asynchronous Transceiver (UART) communication protocol that supports automotive in vehicle networks.
Features
- AEC-Q100 Qualified for Automotive Application
- Meets LIN2.0、LIN2.1、LIN2.2、LIN2.2A and ISO 17987-4:2016(12V) Physical-layer (EPL) Standards
- Compliant to SAE J2602-1 and SAE J2602-2 LIN Physical-layer Specification
- Designed to Support 12V Applications with Wide
- Operating Supply Range
- 5V to 28V supply range (VBAT)
- Support up to 20kbps LIN Transmission Data Rate
- Operating Mode
- Normal operation
- Low-power Standby
- Low-power Sleep
- Wake-up from Low-power Mode
- Remote wake-up via LINx bus
- wake-up via SLPx_N pins
- Integrated 30kΩ LIN pull-up Resistor
- Power-up/down Glitch-free Operation on LIN bus and RXD output
- Integrated Protection Increases Robustness
- ±42V fault-tolerant LIN bus
- 42V load dump protection
- Enhanced ESD protection
Applications
- Body electronics
- Automotive gateway
- Infotainment and cluster
- Hybrid electric vehicles and powertrain systems
Device Information
| Package size(NOM) |
| SOIC14(NF) |
| 3.9mm×8.65mm |
| DFN14(DF) |
| 3mm×4.5mm |
| QFN24(F) |
| 3.5mm×5.5mm |
| CA-IF1022_datasheet_V1.0 |
