Chipanalog CA-IF1051HS Interface IC

Chipanalog CA-IF1051HS

CA-IF1051H is +5V control area network (CAN) transceivers with integrated protection for industrial applications. This device is designed for using in CAN FD networks up to 5 Mbps and features extended ±70V fault protection on the CAN bus for equipment where overvoltage protection is required. This CAN device also incorporates an input common-mode range (CMR) of ±30V, exceeding the ISO 11898 specification of -2V to +7V, and well suited for applications where ground planes from different systems are shifting relative to each other.

Features

• Meets the ISO 11898-2:2016 and ISO 11898-5:2007 physical layer standards
• 'Turbo' CAN
• Support classic CAN and 5 Mbps CAN FD (flexible data rate)
• Short and symmetrical propagation delay times and fast loop times for enhanced timing margin
• Higher data rates in loaded CAN networks
• Ideal passive behavior when unpowered
• Bus and logic terminals are high impedance (no
• load)
• Power up/down with glitch free operation on bus and RXD output
• Integrated protection increases robustness
• ±70V fault-tolerant CANH and CANL
• ±30V extended common-mode input range (CMR)
• Undervoltage protection on VCC supply terminal
• Transmitter dominant timeout prevents lockup, data rates down to 5.5 kbps
• Thermal shutdown
• Junction temperatures from –55°C to 150°C
• Typical loop delay
• 130ns
• Available in SOIC(8) package

Applications

• Industrial automation
• Building automation
• HVAC systems
• Distribution automation
• Vending machines
• Security systems

Device Information
