Chipanalog CA-IF4023 Interface IC

Chipanalog CA-IF4023

The CA-IF4023 is an integrated AISG transceiver which is compliant with the Antenna Interface Standards Group v3.0 specification. Integrated on the chip are the transmitter, receiver, and active filters. This device reduces the hassle and expense of working with discrete solutions and drastically reduces the time needed to implement the AISG protocol.

Features

• Wide Receiver Input Dynamic Range
• -15dBm to +5dBm in 50Ω
• Adjustable Output Power (5.4dBm to 12dBm) Allows Compensation for Losses in External Circuitry and Cabling
• AISG V3.0-compliant Output Emission Profile
• Autodirection Output Simplifies Bus Arbitration in Tower-mounted Equipment
• Supports 9.6kbps、38.4kbps and 115.2kbps AISG Signaling
• Integrated Active Bandpass Filter with Center Frequency at 2.176MHz
• 3.0V to 5.5V Supply Voltage
• 1.6V to 5.5V Independent Logic Supply Voltage
• Low-Power Standby Mode
• Small, 3mm x 3mm, 16-pin QFN Package
• -40°C to +125°C Operating Temperature Range

Applications

• Base Stations
• Tower Equipment
• General Modem Interfaces
