Chipanalog CA-IF4888HS Interface IC

Chipanalog CA-IF4888HS

Features

• Meets Requirements of TIA/EIA-485A Standard
• Bus-Polarity Correction Within 114ms (tFS-max)
• Data Rate
• 300bps to 500kbps
• Supply Voltage
• 3V to 5.5V
• Current-limiting Driver and Thermal Shutdown Function
• Bus I/O ESD Protection
• ±30kV HBM；
• ±8kV IEC 61000-4-2 Contact Discharge
• 1/8 Unit Load (Up to 256 Nodes on a Bus)
• Operating Temperature Range
• –40°C to 125°C
• Common Mode Voltage Range
• ±15V
• Fault Protection Range
• ±30V
• Low Power Current: 960µA (max.) @ Receive Mode
• Standby Current
• Narrow-Body SOIC8 Package

Applications

• Industrial Automation
• HVAC Systems
• DMX512-Networks
• Process Control
• Battery-Powered Applications
• Motion Control
• Simplified Functional Diagram
