Chipanalog CA-IS1300B25G-Q1 Isolated Sensing IC

Chipanalog CA-IS1300B25G-Q1

Features

• Differential Input Voltage Range
• ±250 mV
• Fixed Initial Gain
• 8.2
• Low Input Offset and Drift
• ±0.2 mV (max) at 25°C, ±3.5 μV/°C (max)
• Low Gain Error and Drift
• ±0.3% (max) at 25°C, ±50 ppm/°C (max)
• Low Nonlinearity and Drift
• 0.01% (typ) for Full Scale, ±1 ppm/°C (typ)
• 3.3-V or 5-V Operation for Both High- and Low-Side
• High CMTI
• ±150 kV/µs (typ)
• Wide Operating Temperature Range
• –40°C to 125°C
• Safety-Related Certifications
• 7070-V
• PK
• Isolation per DIN EN IEC 60747-17 (VDE 0884-17)
• 5-kV

Applications

• Automotive Motor Controls and Drives
• Onboard Chargers
• Traction Inverters
• Charging Piles

Device Information
