Chipanalog CA-IS1300G25G Isolated Sensing IC

Chipanalog CA-IS1300G25G

Features

• Differential Input Voltage Range
• ±50 mV or ±250 mV
• Fixed Initial Gain
• 8.2 or 41
• Low Input Offset and Drift
• CA-IS1300G05: ±0.1 mV (max) at 25°C, ±1 μV/°C(max)
• CA-IS1300G25: ±1 mV (max) at 25°C, ±4 μV/°C(max)
• CA-IS1300B25: ±0.2 mV (max) at 25°C, ±4 μV/°C(max)
• Low Gain Error and Drift
• CA-IS1300G05: ±0.3% (max) at 25°C, ±50 ppm/°C(max)
• CA-IS1300G25: ±0.5% (max) at 25°C, ±50 ppm/°C(max)
• CA-IS1300B25: ±0.3% (max) at 25°C, ±50 ppm/°C(max)
• Low Nonlinearity and Drift
• 0.01% (typ) for Full Scale, ±1 ppm/°C (typ)
• 3.3-V or 5-V Operation for Both High- and Low-Side
• High CMTI
• ±150 kV/µs (typ)
• Wide Operating Temperature Range
• –40°C to 125°C
• Safety-Related Certifications

Applications

• Industrial Motor Controls and Drives
• Isolated Switch Mode Supplies
• Uninterruptible Power Supplies

Device Information
