Chipanalog CA-IS1311BG Isolated Sensing IC

Chipanalog CA-IS1311BG

Features

• Input Voltage Range
• –0.1 V to 2 V
• High Input Impedance
• 1 GΩ (typ)
• Fixed Initial Gain
• 1
• Low Input Offset and Drift
• ±1.5 mV (max) at 25°C, ±15 μV/°C (max)
• Low Gain Error and Drift
• ±0.3% (max) at 25°C, ±40 ppm/°C (max)
• 3.3-V or 5-V Operation for Both High- and Low-Side
• Wide Operating Temperature Range
• –40°C to 125°C
• High CMTI
• ±150 kV/µs (typ, CA-IS1311BG)
• Safety-Related Certifications
• 7-kVPK Isolation per DIN EN IEC 60747-17 (VDE 0884-17)
• 5-kVRMS Isolation for 1 Minute per UL 1577
• TUV Certification Approvals
• >40-year Life at Rated Working Voltage

Applications

• Industrial Motor Controls and Drives
• Isolated Switch Mode Supplies
• Uninterruptible Power Supplies

Device Information

Download Datasheet (PDF)
