Chipanalog CA-IS2082B Isolated Interface IC

Chipanalog CA-IS2082B

Features

• High-Performance and Compliant with RS-485 EIA/TIA-485 Standard
• Up to 20Mbps data rate
• 1/8 unit load enables up to 256 nodes on the bus
• 2.375V to 5.5V logic side supply voltage and 3.0V to 5.5 V bus side supply voltage
• Integrated Protection for Robust Communication
• 3.0kVRMS withstand isolation voltage for 60s (galvanic isolation)
• ±100kV/μs typical CMTI
• High lifetime: >40 years
• ±8kV Human Body Model (HBM) ESD on BUS I/O, ±4kV HBM ESD protection on logic I/Os and other pins of bus side
• Short-circuit protection and thermal shutdown
• True fail-safe guarantees known receiver output state
• Wide Operating Temperature Range
• –40°C to 125°C
• Compact SSOP16 (B) Package

Applications

• Industrial automation equipment
• Grid infrastructure
• Solar inverter
• Motor drivers
• HVAC

Device Information
