Chipanalog CA-IS23050W Sensor IC

Chipanalog CA-IS23050W

The CA-IS23050W is a highly accurate and cost-effective current sensor IC suitable for AC/DC current sensing in a variety of industrial, commercial, and communications systems. It features a low-offset, linear Hall sensor circuit and a copper conduction path that generates a magnetic field when current flows through it. The integrated Hall IC senses this magnetic field and converts it into a proportional voltage output, which has a positive slope proportional to the current flowing through the primary copper conduction path. The device senses current differentially, rejecting common-mode fields and improving accuracy in magnetically noisy environments. With its 0.61mΩ internal resistance, the primary copper conduction path offers low power loss and high inrush current withstand capability. The CA-IS23050W is available in a 16-pin wide-body SOIC packages. The CA-IS23050W is rated for operation at working ambient temperatures of -40°C to +125°C.

Features

• Differential hall sensing rejects common-mode fields and nearly zero magnetic hysteresis
• Integrated digital temperature compensation circuitry allows for near closed loop accuracy
• High immunity to external magnetic fields
• Precision zero-current reference output
• Primary conductor resistance
• 0.61mΩ
• High current sense range capability
• ±50APK
• High accuracy
• Total output error: ±3% Max@25°C to +125°C
• Total output error lifetime drift: ±5% Max
• Sensitivity error: ±2.5% Max@25°C to +125°C
• Non-linearity: ±1% Max
• Symmetry: ±1% Max
• Fast response
• Signal bandwidth: 120kHz
• Propagation delay: 2μs
• Response time: 3.7μs
• Operating supply voltage
• 4.5V to 5.5V

Applications

• Solar Energy
• Motor Control
• EC Charging
• Power supplies
