Chipanalog CA-IS3030T Isolated Interface IC

Chipanalog CA-IS3030T

The CA-IS303x devices are high-performance, dual-channel, isolated low-voltage differential signaling (LVDS) buffers with up to 3.75-kVRMS isolation rating and up to 1.1-Gbps ultra-fast data rate. These devices are compliant with TIA/EIA-644-A LVDS standard and offer all possible unidirectional channel configurations to accommodate any 2-channel isolated LVDS I/O applications. The CA-IS3030 features two channels transferring LVDS signals in one direction; The CA-IS3031 and CA-IS3032 devices have 2 channels with 1 channel in each direction The CA-IS303xT devices feature internal LDO. When operating from 3.3V power supply, the integrated LDO generates 2.5V regulated voltage from 3.3V input for LVDS and isolator circuits. The CA-IS303xT LVDS isolator accepts both 2.5V and 3.3V supplies. When operating from 2.5V power supply, connect VDDx to VINx to bypass internal LDO.

Features

• Passes EN55032 Class B Radiated Emissions Limits with Dual-Channel Configuration
• 3.75kVRMS Isolation Rating
• Supply Voltage
• 2.5V or 3.3V
• High CMTI
• >25kV/μs
• Fail-Safe Output High for Open, Short, and Terminated Input Conditions (CA-IS3031T/CA-IS3032T)
• Supports up to 1.1-Gbps Data Rate
• 3.5-ns Typical Propagation Delay
• 5-ps Typical (RMS) Random Jitter
• 120-ps Typical Peak-to-Peak Total Jitter
• Power Supply Ripple Rejection and Glitch Immunity
• −80dBc
• ±6-kV IEC 61000-4-2 ESD Protection on LVDS Ports
• 16-Pin or 20-Pin Wide-Body SOIC Package
• Extended Industrial Temperature Range
• –40°C to 125°C

Applications

• Communication Equipment
• Enterprise System
• Industrial High-Speed Analog-Front Module
• Industrial High-Speed Clock and Data Links
• Simplified Functional Diagram

Download Datasheet (PDF)
