Chipanalog CA-IS3082WW Isolated Interface IC

Chipanalog CA-IS3082WW

have the logic input and output buffers separated by a silicon oxide (SiO2) insulation barrier that provides up to 7.5-

Features

• Meets or Exceeds the Requirements of the TIA/EIA 485A Standard
• 500kbps Data Rate
• 1/8 Unit Load (Up to 256 Bus Nodes)
• Logic-Side Supply Voltage
• 2.375V to 5.5V
• Bus-Side Supply Voltage
• 3V to 5.5V
• Common Mode Range on Bus Pins
• –7V to +12V
• High CMTI
• ±150kV/μs (typ)
• Bus Pins (A/B) ESD Protection
• ±20kV (HBM)
• Driver with Current Limiter and Thermal Shutdown Protection
• Open, Short and Idle Bus Failsafe Protection
• Extended Industrial Temperature Range
• –40°C to 125°C
• 16-Pin Ultra-Wide-Body SOIC Package, creepage and clearance ≥ 15mm
• > 40-Year Lifetime at Rated Isolated Voltage

Applications

• Solar Inverter
• High Voltage Energy Storage Systems
• Railway Transportation
• Wind Power System
• Charging Pile

Device Information
