Chipanalog CA-IS3089WX Isolated Interface IC

Chipanalog CA-IS3089WX

The CA-IS308x family of devices is a galvanically-isolated RS-485/RS-422 transceiver that has superior isolation and RS485 performance to meet the needs of the industrial applications. All devices of this family have the logic input and output buffers separated by a silicon oxide (SiO2) insulation barrier that provides galvanic isolation, features up to 5000VRMS (60s) of galvanic isolation and ±150kV/μs typical CMTI. Isolation improves communication by breaking ground loops and reduces noise where there are large differences in ground potential between ports.

Features

• High-Performance and Compliant with RS-485 EIA/TIA-485 Standard
• 500kbps, 10Mbps or 20Mbps data rate optional
• 1/8 unit load enables up to 256 nodes on the bus
• 2.375V to 5.5V logic side supply voltage and 3 V to 5.5 V bus side supply voltage
• Bus common mode supply rage
• CA-IS3080/86: -15V to +15V
• CA-IS3082/88: -7V to +12V
• CMTI
• ±150kV/μs (typical)
• Output current limited and thermal shutdown protection on driver side
• Open、short circuit protection and bus failure protection
• Wide operating temperature range
• –40°C to 125°C
• Wide-body SOIC16-WB(W) Package
• High lifetime
• >40 years

Applications

• Industrial Automation Equipment
• Grid infrastructure
• Solar inverter
• Motor drivers
• HVAC

Device Information

Download Datasheet (PDF)
