Chipanalog CA-IS3211CVBJ Isolated Gate Driver
Share
p4.7A Source /6A Sink, 5.7kVRMS Opto-Compatible Single-Channel Isolated Gate Driver/p
- Product Details
- Download
Chipanalog CA-IS3211CVBJ
4.7A Source /6A Sink, 5.7kVRMS Opto-Compatible Single-Channel Isolated Gate Driver
Features
- 4.7A Peak Source Current and 6A Peak Sink Current
- Up to 30V Output Drive Supply Range with 8V and 12V UVLO options
- Support Rail to Rail Output
- Up to 7V Reverse Voltage on Input-stage, Interlock
- Matching Propagation Delay
- 80ns Propagation delay (typical)
- 25ns Part to part propagation delay matching (maximum)
- 35ns Pulse width distortion (maximum)
- -40°C to +150°C Operating Junction Temperature Range
- Robust Galvanic Isolation
- High lifetime: >40 years
- Up to 5.7kVRMS isolation rating for the wide-body packages and 3.75kVRMS isolation rating for DUB8 package
- Common-mode transient immunity (CMTI) > ±150kV/μs
- Package options
- 6-pin wide-body SOIC6-WB (J) package
- 6-pin wide-body TSOIC6-WB (TJ) thin package
- 8-pin wide-body SOIC8-WB (G) package
- 8-pin DUB8 (U) package
Applications
- Isolated DC-DC and AC-DC Converters
- Motor Control
- Uninterruptible Power Supply (UPS)
- Isolated Gate Driver for Inverters
Device Information
| Package Size (NOM) |
| CA-IS3211CVBJ |
| SOIC6-WB (J) |
| 4.68mm x 7.50mm x 3.18mm |
| CA-IS3211CVCJ |
| SOIC6-WB (J) |
| 4.68mm x 7.50mm x 3.18mm |
| CA-IS3211CVBTJ |
| TSOIC6-WB (TJ) |
| 4.68mm x 7.50mm x 2.30mm |
| CA-IS3211CVCTJ |
| TSOIC6-WB (TJ) |
