Chipanalog CA-IS3211SCWG Isolated Gate Driver
Share
p6A Sink/5A Source, Opto-Compatible Single-Channel Reinforced Isolated Gate Driver/p
- Product Details
- Download
Chipanalog CA-IS3211SCWG
6A Sink/5A Source, Opto-Compatible Single-Channel Reinforced Isolated Gate Driver
Features
- 6A Peak Sink Current and 5A Peak Source Current
- 13V to 30V Output Side Wide Power Supply
- Support Rail to Rail Output
- Up to 7V Reverse Voltage on Input-stage, Interlock
- Matching Propagation Delay
- 70ns Propagation delay (typical)
- 25ns Part to part propagation delay matching(maximum)
- 35ns Pulse width distortion(maximum)
- -40°C to +150°C Operating Junction Temperature Range
- Robust Galvanic Isolation
- High lifetime: >40 years
- Up to 7.5kVRMS isolation rating for the super wide-body packages
- Common-mode transient immunity (CMTI) > ±100kV/μs
- Package options
- 8-pin super wide-body SOIC8 (WG) Package
Applications
- EV/HEV Charging Piles Meet With IEC61851-23:2023 and GB/T 18487.1-2023
- 1500V/2000V/2500V HV Solar Inverter
- 1500V/2000V/2500V HV PCS
- Uninterruptible Power Supply (UPS)
- HV Industrial Power Supplies
Device Information
| Package Size(NOM) |
| CA-IS3211SCWG |
| 6.40 mm x 14.00mm |
| CA-IS3211SCWG_datasheet_Version1.00_en |
