Chipanalog CA-IS3213VCG Isolated Gate Driver
Share
pCA-IS3213VCG — Isolated Gate Driver by Chipanalog (Chip Analog Microelectronics). Up to 33V Output Drive Supply Range(VDD-VEE) with 12V VDD UVLO Detection/p
- Product Details
- Download
Chipanalog CA-IS3213VCG
Features
- Up to 33V Output Drive Supply Range(VDD-VEE) with 12V VDD UVLO Detection
- 15A Sink/Source Peak Current
- Drive High-power SiC MOSFET and IGBT with up to 2121 VPK Operating Voltage
- Feature selections
- Integrated Miller Clamp (CA-IS3213MCG)
- UVLO refer to COM (CA-IS3213VCG)
- Split output (CA-IS3213SCG)
- Propagation Delay
- 130ns propagation delay (maximum)
- 30ns pulse width distortion (maximum)
- 30ns part to part skew (maximum)
- Robust Galvanic Isolation
- High lifetime: >40 years
- Up to 5.7kVRMS isolation rating
- CMTI > ±150kV/μs
- 8-pin Wide-body SOIC Package with Creepage and Clearance >8mm
- Operating Temperature (TJ)
- -40°C to +150°C
Applications
- UPS and PSU
- Solar Inverters
- Motor Drives
Device Information
| Package Size (Nominal Value) |
| CA-IS3213MCG |
| SOIC8-WB(G) |
| 7.5mm x 5.85mm |
| CA-IS3213VCG |
| SOIC8-WB(G) |
| 7.5mm x 5.85mm |
| CA-IS3213SCG |
| SOIC8-WB(G) |
| 7.5mm x 5.85mm |
