Chipanalog CA-IS3215LNW-Q1 Isolated Gate Driver
Share
pThe CA-IS3215/6 devices are a family of single-channel reinforced isolated gate driver capable of sinking 15A and sourcing 15A peak-current. These devices operate with dual supplies or a single supply of up to 33V wide v/p
- Product Details
- Download
Chipanalog CA-IS3215LNW-Q1
The CA-IS3215/6 devices are a family of single-channel reinforced isolated gate driver capable of sinking 15A and sourcing 15A peak-current. These devices operate with dual supplies or a single supply of up to 33V wide voltage range of VDD - VEE, making them ideal to drive high-power MOSFET, IGBT or silicon-carbide(SiC) transistors in various inverter, motor control or isolated power supply systems.
Features
- 15A Peak Sink Current and 15A Peak Source Current
- OUTH and OUTL Split Outputs
- Drive High-power SiC MOSFET and IGBT with up to 2121 V
- PK
- Operating Voltage
- Up to 33V Output Drive Supply Range(V
- DD
- -V
- EE
- ) with 12V VDD UVLO Detection and Power-Good Indication RDY
- Robust Galvanic Isolation
- Robust Galvanic Isolation
- Up to 5.7kV
- RMS
- isolation rating
- Common-mode transient immunity (CMTI) >±150V/ns
- Input Features Fast Transient/Pulse Reject (
- Integrated Desaturation (DESAT) Protection with 200ns Fast-Response
- 4A Internal Active Miller Clamp
- Inputs and Outputs Features up to 5V Overshoot/Under-shoot Transient Immunity
Applications
- HEV and EV Traction Inverter
- On Board Charger (OBC)
- Automotive High-voltage DC-DC Convertor
Device Information
| Package Size(Nominal Value) |
| CA-IS3215xxW-Q1 |
| SOIC16-WB (W) |
| 10.3 mm x 7.5 mm |
| CA-IS3216xxW-Q1 |
| SOIC16-WB (W) |
| 10.3 mm x 7.5 mm |
| CA-IS3215_6x-Q1_datasheet_Version1.1_en |
