Chipanalog CA-IS3221AA Isolated Gate Driver
Share
pThe CA-IS322x devices are a family of dual-channel isolatedgate drivers capable of sinking 6A and sourcing 5A peakcurrents. These devices have very fast switching time,combined with short propagation delays (56ns, typ) a/p
- Product Details
- Download
Chipanalog CA-IS3221AA
The CA-IS322x devices are a family of dual-channel isolatedgate drivers capable of sinking 6A and sourcing 5A peakcurrents. These devices have very fast switching time,combined with short propagation delays (56ns, typ) andsmall pulse width distortion, making them ideal to drivepower MOSFET, IGBT or silicon-carbide(SiC) transistorswith up to 5MHz frequency in various inverter, isolatedpower supply or motor control applications.
Features
- Support Broad Range of Applications
- Dual low-side, dual high-side drivers
- Half-bridge drivers
- 6A Peak Sink Current and 5A Peak Source Current
- Wide Supply Range
- 3V to 18V Input-side V
- CCI
- supply range
- Up to 25V V
- DD
- _ output drive supply
- Provide 6V、8V and 12V precision UVLO options
- Matching Propagation Delay
- 56ns Propagation delay (Typ.)
- 5ns Propagation delay matching (Max.)
- 7ns Pulse width distortion(Max.)
- 20ns Minimum pulse width(Typ.)
- Programmable Overlap and Dead-time
- -40°C to +125°C Operating Temperature Range
- Robust Galvanic Isolation
Applications
- Isolated DC-DC and AC-DC Converters
- Motor Control
- LED Lighting
- Uninterruptible Power Supply (UPS)
- Isolated Gate Driver for Inverters
- HEV/EV Battery Charger
Device Information
| Package Size (Nominal Value) |
| CA-IS3221 |
| LGA13(A) |
| CA-IS3221_2x-LGA Package Only_Datasheet_Version 1.01_en_20260910 |
| CA-IS322X_V1.2 |
