Chipanalog CA-IS3722CLS Digital Isolator

Chipanalog CA-IS3722CLS

Features

• Data rate
• DC to 40Mbps
• Robust isolation barrier
• High lifetime: >40 years
• Up to 5kVRMS isolation rating (wide‐body packages)
• ±150kV/μs typical CMTI
• Wide supply range
• 3.0V to 5.5V
• Wide operating temperature range
• –40°C to 125°C
• No start‐up initialization required
• Default output High (CA‐IS372xCH) and Low (CA‐ IS372xCL) Options
• High electromagnetic immunity
• Low power consumption
• 2.6mA per channel at 1Mbps with VDDX = 5.0V
• 5.2mA per channel at 40Mbps with VDDX = 5.0V
• Best in class propagation delay and skew
• 22ns typical propagation delay
• 3ns propagation delay skew (chip ‐to‐chip)
• 1ns pulse width distortion

Applications

• Industrial Automation
• Motor Control
• Medical Systems
• Isolated Power Supplies
• Solar Inverters
• Isolated ADC, DAC
• Simplified Functional Diagram
