Chipanalog CA-IS3862HW Digital Isolator

Chipanalog CA-IS3862HW

Features

• Robust Galvanic Isolation of Digital Signals
• High lifetime: >40 years
• Up to 5700 V
• RMS
• isolation rating (wide body packages)
• ±150 kV/μs typical CMTI
• Wide operating temperature range: -40°C to 125°C
• Schmitt trigger inputs
• Interfaces Directly with Most MCUs and FPGAs
• Data rate: DC to 150Mbps
• Accepts 2.5V to 5.5V supplies
• Default output High (CA-IS386xH) and Low (CAIS386xL) Options
• Low Power Consumption
• 1.5mA per channel at 1Mbps with VDD = 5.0V
• 6.6mA per channel at 100Mbps with VDD = 5.0V
• Best in class propagation delay and skew
• 12ns typical propagation delay
• 1ns pulse width distortion
• 2ns propagation delay skew (chip -to-chip)
• 5ns minimum pulse width

Applications

• Solar Inverter
• Wind-Generated Electricity
• High Voltage Power Storage
• High Voltage Grid System
• EV Charging Station
• Medical Electronics

Device Information
