Chipanalog CA-IS3988P Isolated Interface IC

Chipanalog CA-IS3988P

The CA-IS398x family of isolated octal digital inputs are optimized for industrial 24V digital input applications. All devices can be configured for Type 1, Type 2, or Type 3 inputs with a few external components and each channel can sink and source current. The isolation channels based on Chipanalog’s advanced capacitive isolation technology feature up to 2.5kVRMS isolation rating and ±300kV/μs typical CMTI (low-speed channels), provide high electromagnetic immunity, low propagation delay and low jitter.

Features

• Accepts Industry Standard Input Types
• Compliant to IEC 61131-2 Input Types 1, 2, and 3
• High Integration
• Eight input channels with serializer (CA-IS3980S)
• Eight input channels with parallel-outputs (CA-IS398xP)
• Support up to 2Mbps Data Rates
• Integrated Digital Glitch and Debounce Filters with 0 to 100ms Selectable Delay Time
• High transient immunity
• ±300kV/µs CMTI for the low-speed channels
• ±50kV/µs CMTI for the high-speed channels
• 2500VRMS Integrated Isolation Reduces BOM and Footprint
• SPI-Compatible Serial Interface (CA-IS3980S only)
• 2.25V to 5.5V Single Supply
• Eliminates the Need For Field-side Power Supply
• Ambient Operating Temperature
• -40°C to 125°C
• Package
• 8.66mm x 3.91mm 20-pin SSOP

Applications

• Digital Input Modules for PLCs
• Industrial, Building, and Process Automation
• Motor Control
• CNC Control
• Industrial data acquisition

Device Information

Download Datasheet (PDF)
