Chipanalog CS485S
The CS485 family of devices are low-power half-duplex transceivers for RS-485/RS-422 communications in harsh environments. All devices feature ±18kV electro-static discharge (ESD) protection for the bus pins (A and B), eliminating the need for additional system level protection components.
Features
- High-Performance and Compliant with RS-485 EIA/TIA-485 Standard
- Low EMI 250kbps Data Rate
- Allow up to 50 Nodes on the Same Bus
- Integrated Protection for Robust Communication
- -7V to +12V Common-Mode Voltage Range
- ±18kV Human Body Model ESD Protection and ±4kV Contact Discharge IEC 61000-4-2 ESD Protection on A/B pins
- Short-Circuit Protection
- Thermal Shutdown
- True Fail-Safe Guarantees Known Receiver Output State
- Glitch-free
- Low Power
- Low Supply Current (0.95mA, typ.)
- Shutdown Current
- 3V to 5.5V Supply Voltage Range
- Wide Operating Temperature Range
- –40°C to 125°C
- 8 pin SOIC and 8 pin MSOP Packages
Applications
- Factory Automation & Control
- Grid Infrastructure
- Home and Building Automation
- Video Surveillance
- Smart Meters
- Process Control
- Telecommunication Equipment
Device Information
| Package size (NOM) |
| 4.9mm × 3.9mm |
| 3mm × 3mm |
