Chipanalog CS817x22HS Digital Isolator

Chipanalog CS817x22HS

The CS817x20/CS817x22 family of ultra-low-power digital isolators used Chipanalog’s “Pulse-Coding” capacitive isolation technology, offering as low as 90μA per channel low quiescent current. These isolated CMOS compatible digital I/Os feature up to 3kVRMS isolation rating and ±150 kV/μs typical CMTI, provide high electromagnetic immunity and low EMI. All device versions have Schmitt trigger inputs for high noise immunity and each isolation; channel has a logic input and output buffer separated by capacitive silicon dioxide (SiO2) insulation barrier, only require two VDD_ bypass capacitors to build a digital signal isolation solution.

Features

• Ultra Low Power
• 90µA per channel at DC with 3.3V operation
• 100µA per channel at 10kbps with 3.3V operation
• 160µA per channel at 200kbps with 3.3V operation
• Data Rate is up to 200kbps
• Wide Operating Supply Voltage
• 2.375V to 5.5V
• Robust Galvanic Isolation of Digital Signals
• High lifetime: >40 years
• Up to 3kVRMS isolation rating
• ±150 kV/μs typical CMTI
• Schmitt trigger inputs for high noise immunity
• High electromagnetic immunity
• No Start-up Initialization Required
• Wide operating temperature range
• -40°C to 105°C
• Default Output High (CS817x2xHS) and Low (CS817x2xLS) Options
• RoHS-Compliant Package
• SOIC8(S) narrow body

Applications

• Li+ Battery Protection
• Home Appliances
• Industrial automation systems
• Motor control
• Medical electronics
• Isolated switch mode supplies
• Power inverters

Device Information

Download Datasheet (PDF)
