KDS DSB535SGC TCXO 10-52MHz 5.0x3.2x1.5mm
Share
KDS DSB535SGC — TCXO, 10-52MHz, 5.0x3.2x1.5mm SMD. Ultra high precision SMD (VC-) TCXO. Clipped sine output or CMOS level output.
- Product Details
- Download
KDS DSB535SGC TCXO
Ultra High-precision SMD VC-TCXO/TCXO — TCXO, 10-52MHz, 5.0x3.2x1.5 mm.
Features
- 5032 size. 1.35mm height.
- Ultra high precision SMD (VC-) TCXO
- Clipped sine output or CMOS level output
- Low phase noise
- Single packaged structure
Applications
- Stratum3, 5G compatible devices, Networking, Base station
Standard Specification
| Type | DSA535SGC / DSB535SGC / DSA535SGB / DSA535SGA / DSB535SGA |
| Item | （VC-TCXO） / （TCXO） / （VC-TCXO） / （VC-TCXO） / （TCXO） |
| Output Frequency Range | 10 to 52MHz |
| Standard Frequency | 10MHz/19.2MHz/20MHz/38.88MHz |
| Supply Voltage Range | +2.3 to +3.63V |
| Supply Voltage (VCC) | ＋2.8V/＋3.0V/＋3.3V |
| Current Consumption +8.0mA max. (Clipped sine)/+12.0mA max. (CMOS) | +4.0mA max. (Clipped sine)/+8.0mA max. (CMOS) |
| Output Voltage | |
|---|---|
| Output Load | 10kΩ//10pF (Clipped sine)/15pF (CMOS) |
| Frequency Stability | |
| Tolerance | ±1.5×10 -6 max.（After 2 reflows） |
| Characteristic Control | ー / ー |
| Voltage Change | |
| Vcont=+1.5V±1.0V) | |
| Total Frequency Tolerance | ±4.6×10 -6 max. (Including temperature, initial tolerance, supply voltage, load variation, and aging) |
| Frequency Control | ± 3.0 to ±5.0×10 -6 / ±3.0 to ±5.0×10 -6 |
| Control Sensitivity | /Vcont=＋1.5V±1.0V / ー / /Vcont=＋1.5V±1.0V / ー |
| Response Slope | Positive / ー / Positive / ー |
| Phase Noise | 20MHz（typ.） / 20MHz（typ.） / 20MHz（typ.） / 20MHz（typ.） |
| Offset 100Hz | −118dBc/Hz / −120dBc/Hz / −118dBc/Hz / −120dBc/Hz |
| Offset 1kHz | −139dBc/Hz / −141dBc/Hz / −139dBc/Hz / −141dBc/Hz |
| Offset 10kHz | −160dBc/Hz / −160dBc/Hz / −155dBc/Hz / −155dBc/Hz |
| Offset 100kHz | −167dBc/Hz / −167dBc/Hz / −158dBc/Hz / −158dBc/Hz |
| Packing Unit (1) | 1000pcs./reel（φ180），4000pcs./reel（φ330） |
| Moisture Sensitivity Level: LEVEL 1（IPC/JEDEC J-STD-033） | |
