SII SC-20T Crystal Resonator 32.768kHz Thin 0.35mm
Share
pSII SC-20T — Crystal Resonator, 32.768kHz, Thin 0.35mm. Ultra-thin type with a thickness of 0.35mm in 2012 size./p
- Product Details
- Download
SII SC-20T Crystal Resonator
SC-20T — Crystal Resonator, 32.768kHz, Thin 0.35mm.
Features
- Ultra-thin type with a thickness of 0.35mm in 2012 size.
- SMD type suitable for high density surface mounting.
- Excellent shock and heat resistance.
- Pb-free.
- Complies with EU RoHS directive.
- A crystal resonator processed by high reliable photolithographic technology inside.
Standard Specification
| Item | Symbol | Specifications |
|---|---|---|
| Nominal Frequency | f_nom | 32.768kHz |
| Frequency Tolerance | f_tol | ±20 x 10-6 ※Please contact us for inquiries regarding available tolerance. |
| Turnover Temperature | Ti | +25±5ºC |
| Parabolic Coefficient | B | (−0.033±10%) x 10-6/ºC2 |
| Load Capacitance | CL | 6.0pF、7.0pF、9.0pF、12.5pF ※Please contact us for inquiries regarding available CL. |
| Motional Resistance(ESR) | R1 | 75kΩ Max. |
| Absolute Maximum Drive Level | DLmax. | 1.0μW Max. |
| Drive Level | DL | 0.1μW typ. |
| Shunt Capacitance | C 0 | 0.8pF typ. |
| Frequency Ageing | f_age | ±3 x 10-6/Year |
| Operating Temperature | T_use | -40 〜 +85ºC |
| Storage Temperature | T_stg | -55 〜 +125ºC |
