USB 2.0 Type-B 180 Degree Bent-Pin Female Connector - C071199
USB 2.0 Type-B 180 Degree Bent-Pin Female Connector - C071199

USB 2.0 Type-B 180 Degree Bent-Pin Female Connector - C071199

Share

180 Degree Type-B female. SPCC shell, UL94-V0 housing.

  • Rated current: 1.8A for 0.25A for other contacts
  • Rated voltage: 30V DC
  • Contact impedance: 30m Ohm
  • Insulation impedance: 100m Ohm
  • Withstand voltage: 100V
  • Operating temperature: -55 Degree C~+85 Degree C
  • Rubber core: PBT, UL94-V0
  • Terminal: Copper Alloy, half gold tin plated
  • Casing: SPCC, nickel plated
[email protected]
Previous
USB 2.0 Type-B 90 Degree Bent-Pin Female Connector - L000654
usb connector typesUSB A connectorusb charger typesusb 2 connector types
  • Product Details
  • Download

Reverse-mount connector for cable assemblies. 100V withstand voltage.
